SUN HYDRAULICS
SANDWICH BODY
Z6Q

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics Z6Q (Material Number: Z6Q) is a high-quality sandwich manifold designed with an ISO 03 interface and a 40mm body type. This product features cross pilot configurations on ports A and B, allowing for efficient hydraulic flow management in complex systems. The manifold includes two open cavities, designated as T11A, which facilitate versatile hydraulic applications. Constructed from durable 6061-T651 aluminum, the Z6Q manifold is noted for its excellent corrosion resistance and robust performance in demanding environments. However, it is important to note that this aluminum material limits the pressure rating to a maximum of 3000 psi (210 bar). The design incorporates a unique boss profile with radiused corners, providing both aesthetic appeal and functional advantages by removing unnecessary material. This distinctive profiling not only enhances the visual integration when multiple manifolds are stacked but also contributes to the structural integrity of the assembly. The Sun Z6Q manifold does not require anodizing due to its inherent corrosion resistance properties, simplifying logistics and reducing costs associated with additional processing steps. Additionally, the absence of anodizing helps maintain consistent stamping quality and avoids potential issues related to torque or fatigue life commonly associated with such treatments. Ideal for use in hydraulic systems where precise flow control is required, the Sun Hydraulics Z6Q manifold supports seamless integration with other components and ensures reliable operation across various applications by maintaining dry sealing surfaces during assembly.
