SUN HYDRAULICS
Z2Y

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics Z2Y (Material Number: Z2Y) is a line mount manifold featuring a bypass compensator, designed for hydraulic systems. It accommodates both threaded and thru-hole mounting, with two provisions for each type. The manifold is crafted from 6061T651 aluminum, known for its excellent corrosion resistance and adequate strength, making it suitable for various applications where exposure to corrosive environments is a concern. The body type is line mount with no specific interface, and it includes an open cavity size of T5A. The manifold has a mounting hole diameter of 0.34 inches (8.6 mm) with an M10x1.5 6H thread specification and a depth of 0.62 inches (15.7 mm), totaling 22 mounting holes. The port size is specified as 12 BSPP, suitable for high flow requirements in hydraulic circuits. However, it's crucial to consider the maximum system pressure when using this manifold; due to its aluminum construction, it should not be exposed to pressures exceeding 3000 psi (210 bar). This limitation ensures the longevity and reliability of the component under operational conditions. The Sun Hydraulics Z2Y model does not undergo anodizing processes due to factors such as cost implications, logistical challenges, and potential negative impacts on fatigue life and torque performance when removing items from the manifold. Instead, the natural properties of the aluminum used provide sufficient durability without additional surface treatments. This design approach aligns with Sun Hydraulics' focus on delivering robust solutions while maintaining manufacturing efficiency and consistency across their product range.
