SUN HYDRAULICS
YTB
$153.20 USD
Tags:
- SUN HYDRAULICS
- Material:YTB
- Summary:Manifold
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics YTB (Material Number: YTB) is a motor mount manifold specifically designed for hydraulic systems, interfacing with Eaton Char-Lynn 2000 motors. This product features a cross pilot body type and open cavities, with a T-2A cavity and SAE 10 port size. The YTB is crafted from 6061-T651 aluminum, known for its excellent corrosion resistance and durability in various environments. This choice of material ensures the manifold can withstand pressures up to 3000 psi (210 bar), making it suitable for demanding hydraulic applications. The design facilitates control and protection of hydraulic motors, providing efficient fluid management within the system. The manifold's construction does not include anodizing, as Sun Hydraulics opts to maintain the natural properties of 6061 aluminum to prevent issues such as increased breakaway torque and reduced fatigue life. This product is ideal for applications requiring robust performance without the need for additional surface treatments that could compromise its integrity under pressure.
The Sun Hydraulics YTB (Material Number: YTB) is a motor mount manifold specifically designed for hydraulic systems, interfacing with Eaton Char-Lynn 2000 motors. This product features a cross pilot body type and open cavities, with a T-2A cavity and SAE 10 port size. The YTB is crafted from 6061-T651 aluminum, known for its excellent corrosion resistance and durability in various environments. This choice of material ensures the manifold can withstand pressures up to 3000 psi (210 bar), making it suitable for demanding hydraulic applications. The design facilitates control and protection of hydraulic motors, providing efficient fluid management within the system. The manifold's construction does not include anodizing, as Sun Hydraulics opts to maintain the natural properties of 6061 aluminum to prevent issues such as increased breakaway torque and reduced fatigue life. This product is ideal for applications requiring robust performance without the need for additional surface treatments that could compromise its integrity under pressure.
Body Type | Motor mountMotor mount |
Interface | Eaton/Char-Lynn 2000Eaton/Char-Lynn 2000 |
Body Features | Cross pilotCross pilot |
Open Cavities | 22 |
Cavity | T-2A |
Port Size | SAE 10SAE 10 |
Show FAQ
Additional Resources
- QuickDesign with SmartConnect Offers Drag-and-Drop Schematic Tool
- Sun Hydraulics' Motor Mount Manifolds Facilitate Control and Protection of Hydraulic Motors
- Manufacturing Sun Cartridge Cavities
- QuickDesign & SunDesign: Sun's 3- & 5-Axis Solutions
- Manifolds: Materials of Construction
- Sun's Floating Style Screw-In Cartridge
- Sun Model Code Explanation; 999-901-334
- Custom Integrated Packages from Sun
- Fluid and Temperature Recommendations
Notes:
- Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
