SUN HYDRAULICS
XQCAXXV
$165.30 USD
Tags:
- SUN HYDRAULICS
- Material:XQCAXXV
- Model:XQCA-XXV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics XQCAXXV (XQCAXXV) is a specialized cavity plug designed to block all ports within hydraulic systems. This component is crafted for the T-24A cavity and belongs to the Series 4 range, which is known for its robust performance under high-pressure conditions, supporting a maximum operating pressure of 5000 psi or 350 bar. The installation of this valve requires a torque between 350 and 375 lbf ft (474 to 508 Nm), and it features a hex size of 1 5/8 inches (41.3 mm). For optimal sealing performance, this cartridge utilizes Viton seals, with the seal kit available under part number 990024006. The XQCAXXV plug is part of Sun's innovative Series 4 PLUS line, which offers higher flow rates while minimizing pressure losses, making it an excellent choice for applications demanding efficient fluid control and minimal maintenance. Additionally, Sun Hydraulics provides zinc-nickel plating on this product for enhanced corrosion resistance, ensuring durability in harsh environments. This cavity plug is compatible with Sun\u2019s QuickDesign with SmartConnect system, allowing users to easily integrate it into complex hydraulic schematics using drag-and-drop functionality. It also supports the use of EPDM seals if required by specific applications. The XQCAXXV's construction adheres to Sun's high standards for materials and manufacturing processes, ensuring reliable performance across diverse operational settings.
The Sun Hydraulics XQCAXXV (XQCAXXV) is a specialized cavity plug designed to block all ports within hydraulic systems. This component is crafted for the T-24A cavity and belongs to the Series 4 range, which is known for its robust performance under high-pressure conditions, supporting a maximum operating pressure of 5000 psi or 350 bar. The installation of this valve requires a torque between 350 and 375 lbf ft (474 to 508 Nm), and it features a hex size of 1 5/8 inches (41.3 mm). For optimal sealing performance, this cartridge utilizes Viton seals, with the seal kit available under part number 990024006. The XQCAXXV plug is part of Sun's innovative Series 4 PLUS line, which offers higher flow rates while minimizing pressure losses, making it an excellent choice for applications demanding efficient fluid control and minimal maintenance. Additionally, Sun Hydraulics provides zinc-nickel plating on this product for enhanced corrosion resistance, ensuring durability in harsh environments. This cavity plug is compatible with Sun\u2019s QuickDesign with SmartConnect system, allowing users to easily integrate it into complex hydraulic schematics using drag-and-drop functionality. It also supports the use of EPDM seals if required by specific applications. The XQCAXXV's construction adheres to Sun's high standards for materials and manufacturing processes, ensuring reliable performance across diverse operational settings.
This cavity plug blocks all ports.
Cavity | T-24A |
Series | 4 |
Maximum Operating Pressure | 5000 psi350 bar |
Valve Hex Size | 1 5/8 in.41,3 mm |
Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
Seal kit - Cartridge | Viton: 990-024-006 |
