SUN HYDRAULICS
XJM

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics XJM (Material Number: XJM) is a robust line mount manifold designed for hydraulic systems requiring efficient fluid control and distribution. This model features an inline, cross pilot body type with no specific interface, making it highly versatile for various applications. The manifold is constructed from 6061T651 aluminum, known for its excellent corrosion resistance and structural strength, ensuring durability even in demanding environments. It includes two open cavities and is designed to accommodate SAE 16 port sizes, which are standard in many hydraulic applications. The XJM model is engineered with a T17A cavity and has a mounting hole diameter of .41 inches (10.4 mm), with a through depth for secure installation using two mounting holes. This manifold is particularly suitable for high-flow valve systems due to its efficient design that supports optimal fluid dynamics. It does not undergo anodizing processes to avoid increased costs, logistical challenges, and potential reductions in fatigue life that anodizing can cause. Instead, it relies on the inherent properties of 6061T651 aluminum to maintain performance without additional surface treatments. When implementing the Sun Hydraulics XJM manifold in your hydraulic system, it\u2019s crucial to consider the maximum system pressure limits; aluminum manifolds like this one are not rated for pressures exceeding 3000 psi (210 bar). This consideration ensures safe operation within specified parameters while taking full advantage of the manifold's capabilities in distributing hydraulic fluid efficiently across connected components.
