SUN HYDRAULICS
XC5

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics XC5 (Material Number: XC5) is a line mount hydraulic manifold designed for effective fluid management in various systems. This model features a cross port with a shuttle on port 3, providing efficient flow control and system integration capabilities. It is constructed with two open cavities, specifically using the T-17A cavity type, ensuring compatibility with specific hydraulic components. The manifold's port size is specified as 1 1/4 Code 62, making it suitable for applications requiring robust flow capacity and connection integrity. The XC5 is manufactured using high-quality 6061-T651 aluminum, known for its excellent corrosion resistance and structural integrity under demanding conditions. This choice of material makes the XC5 particularly suitable for environments where exposure to corrosive elements might be a concern, although it is important to note that the aluminum construction limits the pressure rating to a maximum of 3000 psi (210 bar). This consideration makes the XC5 ideal for medium-pressure hydraulic systems where weight and corrosion resistance are critical factors. Designed without anodization, this manifold avoids potential drawbacks such as increased breakaway torque or reduced fatigue life commonly associated with anodized surfaces. The XC5\u2019s design prioritizes durability and ease of inspection while maintaining a consistent performance standard across its operational lifespan. Its application flexibility makes it an excellent choice for standard line mount installations requiring reliable shuttle valve functionality within hydraulic circuits.
