SUN HYDRAULICS
XBD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics XBD (Material Number: XBD) is a line mount hydraulic manifold designed for versatile fluid control applications. This model features a cross port with a shuttle on port 3, allowing for efficient flow management in hydraulic systems. It is constructed with two open cavities, identified as T2A, and utilizes 3/4 NPTF port sizes, making it compatible with a range of hydraulic components. The manifold is crafted from 6061T651 aluminum, known for its excellent corrosion resistance and strength-to-weight ratio, making it suitable for demanding environments. However, it is important to note that the manifold is not anodized, which can affect its surface wear characteristics but enhances its fatigue life by avoiding the brittleness introduced by anodizing processes. The XBD model's design ensures reliable performance under pressures up to 3000 psi (210 bar), provided that this limit aligns with the overall system's pressure capabilities and material constraints. Its compact and robust construction makes it ideal for use in various hydraulic systems where space and weight are considerations. The manifold's interface design does not include additional features or adaptations, focusing instead on straightforward integration into existing systems. This product serves as a critical component in hydraulic circuits requiring precise flow control and directional changes facilitated by the shuttle valve mechanism. When designing or upgrading hydraulic systems, the Sun Hydraulics XBD manifold offers flexibility and reliability needed to maintain operational efficiency across diverse applications.
