SUN HYDRAULICS
W7X

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics W7X (Material Number: W7X) is a robust line mount manifold designed for efficient hydraulic flow management. This model features a ninety-degree, panel-mount body type, making it suitable for compact and space-conscious installations. The manifold includes four M5x0.8 6H mounting holes, each with a depth of 9.7 mm (.38 inches), ensuring secure attachment and stability in various configurations. It is equipped with a single open cavity, specifically the T-11A cavity, which allows for versatile cartridge valve integration. The W7X manifold utilizes 6061 aluminum, known for its excellent corrosion resistance and strength-to-weight ratio, making it ideal for demanding environments where durability is crucial. The port size of this model is 3/8 BSPP, providing compatibility with standard hydraulic connections and ensuring smooth fluid transfer within hydraulic systems. While the manifold's design does not include anodizing to enhance corrosion resistance further or provide a hard wear surface, the choice of 6061 aluminum mitigates these concerns due to its inherent properties. This decision also minimizes costs and logistical challenges associated with additional processing steps like anodizing. Overall, the Sun Hydraulics W7X is engineered to deliver reliable performance in hydraulic applications requiring robust and adaptable flow management solutions. Its construction supports pressures up to 3000 psi (210 bar), making it suitable for a wide range of hydraulic systems while maintaining structural integrity under demanding conditions.
