SUN HYDRAULICS
SQHBQAV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SQHBQAV (SQHBQAV) is a kickdown sequence valve designed to kick completely open and remain open once the pressure at inlet port 1 exceeds the valve setting, facilitating an unrestricted flow path from port 1 to port 2. The valve remains open as long as the pressure at port 1 surpasses that at port 2, and it resets when the pressure at port 1 falls below its setting with no flow from port 1 to port 2, and when pressure at port 2 is equal to or greater than at port 1. All three-port sequence cartridges are interchangeable in terms of flow path and cavity for a given frame size. This model should not be utilized in load-holding applications. It features a main stage orifice protected by a 150-micron stainless steel screen and can handle pressures up to a maximum of 5000 psi (350 bar). The valve is intended for use on the actuator side of systems, requiring cessation of flow through the valve for resetting; if used on the pump side, pump flow must be halted for reset. The design incorporates Sun's floating style construction to minimize internal part binding due to excessive installation torque or machining variations. The SQHBQAV has a capacity of up to 60 gpm (240 L/min) with factory pressure settings established at kickdown points. It has a typical response time of approximately 25 ms and a maximum leakage rate of about 4 in\u00b3/min (65 cc/min) at standard viscosity conditions. Adjustments can be made via clockwise turns, with specific torque requirements for installation and adjustments provided in its specifications. The model weighs approximately 1.50 lb (0.70 kg) and includes a Viton seal kit option under part number 990017006.
