SUN HYDRAULICS
RVGSLWV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVGSLWV (RVGSLWV) is a ventable, pilot-operated, balanced poppet relief cartridge designed for precise pressure regulation in hydraulic systems. This valve remains closed until the inlet port pressure reaches the preset threshold, at which point it opens to throttle flow to the tank port, thereby regulating the system pressure. Featuring a vent port for remote control by other pilot or 2-way valves, it ensures accuracy with minimal pressure rise versus flow and operates smoothly and quietly. The internal modulating mechanism makes it resistant to cavitation-related issues like noise and manifold erosion. Suitable for load-holding applications, it requires zero-leak valving on the vent port to function effectively. This cartridge is compatible with phosphate ester fluid systems when configured with EPDM seals but should not be exposed to petroleum-based fluids as they can damage the seals. It can handle maximum pressure at port 2 and is suitable for cross-port relief circuits. The valve's design allows for control below its setting through a remote pilot relief on the vent port. It maintains performance despite varying oil temperatures and contamination levels, thanks to its stainless steel screen-protected main stage orifice. The valve's installation features include a cavity T-17A series 3 capacity of 50 gpm (200 L/min) and a maximum operating pressure of 5000 psi (350 bar). It exhibits low leakage rates at reseat with an adjustment mechanism that provides precise control over settings via clockwise turns. The valve incorporates Sun's floating style construction to prevent internal binding due to excessive torque or machining variations, ensuring reliable operation in demanding applications.
