SUN HYDRAULICS
RVGDKEN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVGDKEN (RVGDKEN) is a ventable, pilot-operated, balanced piston relief cartridge with an external drain, designed to function as a normally closed pressure regulating valve. This model is engineered to open to tank port 2 when the inlet port 1 pressure reaches the preset valve setting, effectively throttling flow to maintain regulated pressure. It features a vent port 3 for remote control by other pilot or two-way valves and a drain port 4 that ensures insensitivity to back pressure. The RVGDKEN is known for its accuracy, smooth and quiet operation, low-pressure rise versus flow characteristics, and moderate speed. This relief cartridge can handle maximum pressure at port 2 and is suitable for cross-port relief circuits; however, spool leakage should be considered in such applications. It's important to note that this model is not recommended for load-holding applications due to potential spool leakage. The main stage orifice protection includes a 150-micron stainless steel screen. Additionally, the pressure at port 4 directly adds to the valve setting at a 1:1 ratio with a maximum of 5000 psi (350 bar). The Sun floating style construction minimizes internal binding risks due to excessive installation torque or cavity/cartridge machining variations. The RVGDKEN has a cavity T-23A series with a capacity of up to 60 gpm (240 L/min), operates at pressures up to 5000 psi (350 bar), and has a typical response time of about 10 ms. Its maximum valve leakage rate is specified as four in\u00b3/min at 1000 psi (65 cc/min at 70 bar). Installation requires specific torques: valve installation torque between 150-160 lbf ft (203-217 Nm), adjustment screw internal hex size of ^5/32 in (4 mm), locknut hex size ^9/16 in (15 mm), and locknut torque between 80-90 lbf in (9-10 Nm). The model weight stands at approximately 1.60 lb (0.70 kg) with Viton seal kit option available under part number 990023006.
