SUN HYDRAULICS
H7X

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics H7X (Material Number: H7X) is a line mount manifold designed for hydraulic systems requiring efficient flow management. It features a through port 1 with a reverse flow check, enhancing its ability to manage directional flow effectively. The manifold is constructed to accommodate M10x1.5 6H mounting holes with a depth of .62 inches (15.7 mm), and it includes two such mounting holes to ensure secure installation. It is designed with an open cavity T-17A and offers a port size of 1 BSPP, making it versatile for various hydraulic applications. Crafted from 6061T651 aluminum, the manifold boasts excellent corrosion resistance, making it suitable for environments where exposure to corrosive elements might be a concern. This material choice ensures durability while maintaining cost-effectiveness and machinability. The manifold is not anodized, which helps avoid issues related to increased breakaway torque and fatigue life reduction often associated with anodized surfaces. This product is particularly beneficial in systems that require reliable reverse flow prevention and efficient fluid handling without compromising on structural integrity under pressure. However, it's important to note that manifolds made from aluminum are not rated for pressures exceeding 3000 psi (210 bar), so careful consideration of system pressure is necessary when integrating this component into your hydraulic setup.
