SUN HYDRAULICS
H7L

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics H7L (Material Number: H7L) is a line mount manifold designed for hydraulic systems requiring efficient flow management. This model features a through port 1 with a reverse flow check, providing enhanced control over fluid direction and preventing backflow, which is crucial in maintaining system integrity. The manifold accommodates an SAE 12 port size and is equipped with two mounting holes threaded at .375-16 UNC 2B, each with a depth of .62 inches (15.7 mm). It includes one open cavity (T-17A), allowing for the integration of additional hydraulic components or custom configurations as needed. Constructed from 6061-T651 aluminum, the H7L offers excellent corrosion resistance and durability, making it suitable for various demanding environments. The material choice ensures that the manifold can withstand pressures up to 3000 psi (210 bar), though users should carefully consider system pressure requirements to ensure compatibility and safety. The design does not include anodizing, which helps maintain cost-effectiveness while avoiding potential issues such as increased breakaway torque or reduced fatigue life associated with anodized surfaces. The H7L manifold's robust construction and thoughtful design make it an ideal choice for applications where high flow rates and reliable performance are essential. Its compatibility with Sun's cartridge cavities provides flexibility in system design, allowing users to tailor the manifold to specific operational needs efficiently.
