SUN HYDRAULICS
H7F

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics H7F (Material Number: H7F) is a robust line mount manifold designed for hydraulic systems requiring efficient flow management and reverse flow prevention. This manifold features a through port 1 with a reverse flow check, ensuring optimal performance in applications where unidirectional flow control is critical. The H7F model is engineered with a T17A cavity and accommodates a 1-14 NPTF port size, making it versatile for various hydraulic setups. It includes two mounting holes threaded at .375-16 UNC 2B, each with a depth of .62 inches (15.7 mm), providing secure installation options. The manifold is constructed from high-quality 6061-T651 aluminum, chosen for its excellent corrosion resistance and strength-to-weight ratio, although it is not anodized to avoid potential issues such as increased breakaway torque and reduced fatigue life. This material choice allows the manifold to withstand pressures up to 3000 psi (210 bar), making it suitable for demanding environments where reliability is paramount. The Sun Hydraulics H7F manifold's design facilitates seamless integration into existing systems while maintaining durability and performance under high-pressure conditions.
