SUN HYDRAULICS
H6F

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics H6F (Material Number: H6F) is a line mount hydraulic manifold designed for high-flow applications. Featuring a ninety-degree body type with a reverse flow check sequence, this manifold is engineered to optimize fluid control and direction in hydraulic systems. It includes two mounting holes with a diameter of 0.41 inches (10.4 mm) that go through the entire body, allowing for secure installation in various configurations. The manifold is equipped with one open cavity and uses the T-17A cavity type, providing versatility in accommodating different cartridge valves. With a port size of 1 1/4 NPTF, it ensures compatibility with standard fittings and connections in hydraulic circuits. Constructed from 6061-T651 aluminum, the H6F manifold offers excellent corrosion resistance and durability, making it suitable for demanding environments where reliability is critical. The choice of material also contributes to its relatively lightweight design while maintaining structural integrity under pressure conditions up to 3000 psi (210 bar). This makes it ideal for applications requiring robust performance without compromising on weight or space constraints. The H6F manifold's design facilitates efficient fluid management in hydraulic systems by allowing precise control over flow paths and reducing potential pressure losses associated with more complex setups. Its straightforward installation process and compatibility with high-flow valves make it a practical solution for enhancing system performance across various applications requiring dependable hydraulic control components.
