SUN HYDRAULICS
FRDBXBV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FRDBXBV (Material Number: FRDBXBV) is a 2-port restrictive flow control valve designed to fit into a 3-port cavity, with no connection to port 2 of the cavity. This valve requires the customer to specify a flow rating, with factory-set flow ratings accurate within \u00b110% of the requested setting. It features a sharp-edged orifice design that minimizes flow variations due to changes in viscosity. Additionally, it offers a tunable adjustment control option that allows for up to a \u00b125% variation from the nominal factory preset flow, which can be adjusted using three turns of the adjust screw; turning clockwise increases flow. The valve incorporates Sun's floating style construction, reducing the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. It fits into cavity T-2A and belongs to Series 2, with a capacity of 12 gpm (45 L/min). The maximum operating pressure is rated at 5000 psi (350 bar), and it can handle maximum input flows up to 30 gpm (120 L/min). The valve has a hex size of 1-1/8 inches (28.6 mm) and should be installed with a torque between 45-50 lbf-ft (61-68 Nm). The adjustment screw has an internal hex size of 5/32 inches (4 mm), while the locknut hex size is 9/16 inches (15 mm), with locknut torque specified at 80-90 lbf-in (9-10 Nm). The model weighs approximately .40 lb (.20 kg) and uses Viton seal kits for cartridge sealing. This product is ideal for applications where precise control over fluid flow is required, ensuring consistent performance even in varying conditions.
