SUN HYDRAULICS
FPHKEEV2F24V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FPHKEEV2F24V (FPHKEEV2F24V) is a pilot-operated, normally closed, electroproportional throttle valve with a reverse free flow check. This design allows for metered flow from port 1 to port 2 while enabling reverse free flow from port 2 to port 1. The valve operates efficiently under pressures up to 5000 psi and incorporates interchangeable coils that can be mounted in either direction on the tube. It features several manual override options, including a momentary twist override that shifts the valve by twisting the manual control clockwise by 90 degrees. This versatility ensures adaptability in various applications where precise control is required. For optimal performance, it is recommended to use an amplifier with current sensing and adjustable dither between 100-250 Hz. The cartridge construction minimizes the risk of internal parts binding due to excessive installation torque or machining variations. With a cavity size of T16A and a series number of 3, this valve has a capacity of handling up to 60 gpm (240 L/min). The deadband is nominally set at 25% of input, ensuring precise control over fluid dynamics within hydraulic systems. The FPHKEEV2F24V model has a hex size of 1\u00bc inches (31.8 mm) and requires an installation torque between 150-160 lbf ft (203-217 Nm). Weighing approximately 1.50 lbs without coil and around 2 lbs with coil, it maintains a compact form factor suitable for various hydraulic setups. The Viton seal kits available for both cartridge and coil ensure durability and reliability in demanding environments.
