SUN HYDRAULICS
EMC

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics EMC (EMC) is a line mount manifold designed to provide efficient hydraulic fluid distribution in various applications. This component features a cushion lock body type, which ensures secure and stable connections, and is equipped with two open cavities that utilize the T11A cavity configuration. The manifold accommodates a port size of 12 NPTF, facilitating compatibility with standard hydraulic systems. It includes two mounting holes with a diameter of .34 inches (8.6 mm) that extend through the body for straightforward installation. Constructed from 6061T651 aluminum, the EMC manifold exhibits excellent corrosion resistance, making it suitable for environments where durability is essential. However, it is important to note that this material limits the maximum pressure rating to 3000 psi (210 bar), regardless of the specified port size or type. This restriction should be carefully considered when integrating the manifold into high-pressure systems. The EMC manifold does not feature an anodized finish, as Sun Hydraulics prioritizes maintaining the material's inherent fatigue life and avoiding potential complications associated with anodizing processes, such as increased breakaway torque and reduced fatigue resistance. Consequently, this design choice supports long-term reliability under specified operating conditions. Overall, the Sun Hydraulics EMC line mount manifold is an optimal choice for hydraulic systems requiring robust fluid management solutions within its pressure limitations. Its compatibility with high-flow valves and ease of installation make it a versatile component for various hydraulic applications.
