SUN HYDRAULICS
E3V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics E3V (Material Number: E3V) is a line mount manifold specifically designed for hydraulic systems requiring efficient flow management. This model features a through port 2 with a reverse flow check, enhancing its capability to manage directional flow effectively. It accommodates an M10x1.5 6H mounting hole thread and has a depth of 0.62 inches (15.7 mm), with two mounting holes provided for secure installation. The manifold is built with one open cavity, identified as T-11A, and is compatible with a 12 BSPP port size, ensuring versatility across various hydraulic configurations. The E3V manifold is constructed from high-quality 6061T651 aluminum, known for its strength and corrosion resistance, making it suitable for demanding environments where durability is crucial. Despite the robust nature of the material, this manifold is not anodized, which helps maintain cost-effectiveness while avoiding additional processing complexities that could affect performance characteristics like fatigue life. This product is ideal for applications requiring reliable fluid control in hydraulic systems operating at pressures up to 3000 psi (210 bar). Its design ensures optimal performance in systems where maintaining precise control over fluid direction and pressure is necessary. The inclusion of standard line mount interfaces allows it to be seamlessly integrated into existing setups or new installations without extensive modifications. Overall, the Sun Hydraulics E3V manifold offers an efficient solution for managing hydraulic flow while maintaining structural integrity under specified pressure conditions. Its compatibility with high-flow valves further enhances its application scope in various hydraulic operations.
