SUN HYDRAULICS
CXIEXAN
$197.60 USD
Tags:
- SUN HYDRAULICS
- Material:CXIEXAN
- Model:CXIE-XAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXIEXAN (CXIEXAN) is a versatile and reliable hydraulic check valve designed for high-pressure applications. This model operates as a standard 2-port check valve within a 3-port cavity configuration, with the third port effectively blocked, making it ideal for circuits that require a check valve in pre-existing three-port cavities. The CXIEXAN is distinguished by its ability to handle pressures up to 5000 psi (350 bar) at ports 1 and 2, ensuring robust performance in demanding settings. With an impressive capacity of up to 120 gpm (480 L/min), this valve accommodates substantial flow rates, making it suitable for various hydraulic systems. It features extremely low leakage rates, not exceeding 1 drop per minute (0.07 cc/min), which contributes significantly to system efficiency and reliability. The construction of the CXIEXAN includes Sun's floating style design which minimizes potential internal parts binding that could result from excessive installation torque or variations in cavity/cartridge machining. The valve itself is corrosion-resistant, designed specifically for use in corrosive environments, although specific models like those ending in AP or LH should be referred to for severe conditions. Installation specifications include a hex size of 1-5/8 inches (41.3 mm) and an installation torque range between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm). Weighing at approximately 1.90 lbs (0.85 kg), the CXIEXAN maintains a compact and manageable profile for integration into various setups without adding significant weight or bulk. This model's adaptability and robust construction make it an excellent choice for hydraulic systems requiring reliable check valves capable of operating under high pressure while maintaining minimal leakage and resistance against corrosive elements.
The Sun Hydraulics CXIEXAN (CXIEXAN) is a versatile and reliable hydraulic check valve designed for high-pressure applications. This model operates as a standard 2-port check valve within a 3-port cavity configuration, with the third port effectively blocked, making it ideal for circuits that require a check valve in pre-existing three-port cavities. The CXIEXAN is distinguished by its ability to handle pressures up to 5000 psi (350 bar) at ports 1 and 2, ensuring robust performance in demanding settings. With an impressive capacity of up to 120 gpm (480 L/min), this valve accommodates substantial flow rates, making it suitable for various hydraulic systems. It features extremely low leakage rates, not exceeding 1 drop per minute (0.07 cc/min), which contributes significantly to system efficiency and reliability. The construction of the CXIEXAN includes Sun's floating style design which minimizes potential internal parts binding that could result from excessive installation torque or variations in cavity/cartridge machining. The valve itself is corrosion-resistant, designed specifically for use in corrosive environments, although specific models like those ending in AP or LH should be referred to for severe conditions. Installation specifications include a hex size of 1-5/8 inches (41.3 mm) and an installation torque range between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm). Weighing at approximately 1.90 lbs (0.85 kg), the CXIEXAN maintains a compact and manageable profile for integration into various setups without adding significant weight or bulk. This model's adaptability and robust construction make it an excellent choice for hydraulic systems requiring reliable check valves capable of operating under high pressure while maintaining minimal leakage and resistance against corrosive elements.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-19A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 1.90 lb0,85 kg |
| Seal kit - Cartridge | Viton: 990-019-006 |
