SUN HYDRAULICS
CXHFXHN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXHFXHN (CXHFXHN) is a high-performance hydraulic valve designed specifically for hot oil shuttle applications within partsinbody systems. It features a unique assembly where two valves are positioned nose to nose with a pin in between, forming an effective low side shuttle mechanism. This configuration is essential for applications requiring precise control over fluid flow in high-temperature environments. This model is housed in a T16A cavity and belongs to the Series 3 lineup from Sun Hydraulics, known for its robustness and reliability. The CXHFXHN can handle a substantial flow rate of up to 40 gallons per minute (approximately 160 liters per minute), making it suitable for systems with high fluid throughput requirements. The valve has a hex size of 1 1/4 inches (31.8 mm) and requires an installation torque between 150 - 160 lbf ft (203 - 217 Nm), ensuring secure fitting and optimal performance under varying pressures. Additionally, the CXHFXHN uses Viton seals (part number: 990016006), which are renowned for their high resistance to temperature extremes and chemical interactions, further enhancing the valve's durability and reliability in challenging operating conditions. This model is designed as a direct-acting valve, which is preferred for applications where quick response and tolerance to contamination are critical. Overall, the Sun Hydraulics CXHFXHN valve is an excellent choice for engineers looking to maintain efficient control over hydraulic systems in environments dealing with hot oils and requiring precise shuttle operations. Its robust construction, compatibility with high flow rates, and use of high-quality materials ensure long-lasting performance and reliability.
