SUN HYDRAULICS
CXGBXFV
$166.70 USD
Tags:
- SUN HYDRAULICS
- Material:CXGBXFV
- Model:CXGB-XFV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXGBXFV (CXGBXFV) is a robust check valve designed for hydraulic systems requiring reliable one-way flow control. This model features a free flow from inlet port 2 to outlet port 1 while effectively blocking flow in the reverse direction. The valve is engineered with a Delrin seat, making it particularly suitable for medium pressure systems that may contain some degree of contamination, though it is not ideal for high flow or high temperature environments. The CXGBXFV uses Sun Hydraulics' floating style construction which minimizes potential internal binding due to excessive installation torque or variations in cavity/cartridge machining. This design ensures consistent performance and durability under various installation conditions. The valve operates efficiently with an extremely low maximum leakage rate of less than 1 drop per minute (0.07 cc/min), ensuring minimal fluid loss and enhanced system efficiency. Key technical specifications include a maximum operating pressure of 3000 psi (210 bar) and a capacity of up to 60 gpm (240 L/min). It fits within a T16A cavity and belongs to the Series 3 line of Sun Hydraulics products. The valve has an installation torque requirement between 150 - 160 lbf.ft (203 - 217 Nm) and weighs approximately 1.60 lb (0.70 kg). For maintenance or repair, Viton seal kits and cartridges are available under part number 990016006. This check valve is particularly useful as a circuit saver in systems where manifold drillings may be incorrect, offering a practical solution without the need for extensive system modifications. Its design and construction make it an excellent choice for applications requiring reliable non-return functionality in contaminated or medium pressure hydraulic systems.
The Sun Hydraulics CXGBXFV (CXGBXFV) is a robust check valve designed for hydraulic systems requiring reliable one-way flow control. This model features a free flow from inlet port 2 to outlet port 1 while effectively blocking flow in the reverse direction. The valve is engineered with a Delrin seat, making it particularly suitable for medium pressure systems that may contain some degree of contamination, though it is not ideal for high flow or high temperature environments. The CXGBXFV uses Sun Hydraulics' floating style construction which minimizes potential internal binding due to excessive installation torque or variations in cavity/cartridge machining. This design ensures consistent performance and durability under various installation conditions. The valve operates efficiently with an extremely low maximum leakage rate of less than 1 drop per minute (0.07 cc/min), ensuring minimal fluid loss and enhanced system efficiency. Key technical specifications include a maximum operating pressure of 3000 psi (210 bar) and a capacity of up to 60 gpm (240 L/min). It fits within a T16A cavity and belongs to the Series 3 line of Sun Hydraulics products. The valve has an installation torque requirement between 150 - 160 lbf.ft (203 - 217 Nm) and weighs approximately 1.60 lb (0.70 kg). For maintenance or repair, Viton seal kits and cartridges are available under part number 990016006. This check valve is particularly useful as a circuit saver in systems where manifold drillings may be incorrect, offering a practical solution without the need for extensive system modifications. Its design and construction make it an excellent choice for applications requiring reliable non-return functionality in contaminated or medium pressure hydraulic systems.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- The Delrin seat is suitable for dirty, medium pressure systems that are not subjected to high flows or temperatures.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 60 gpm240 L/min. |
| Maximum Operating Pressure | 3000 psi210 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.60 lb0,70 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
