SUN HYDRAULICS
CXEDLZV
$56.70 USD
Tags:
- SUN HYDRAULICS
- Material:CXEDLZV
- Model:CXED-LZV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXEDLZV (CXEDLZV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model is distinguished by its free flow from the inlet port 2 to the outlet port 1, while effectively blocking flow in the reverse direction. The CXEDLZV is particularly useful as a circuit saver in systems where manifold drillings may be incorrect, offering an efficient solution without the need for extensive rework. With a capacity of 30 gpm (120 L/min) and maximum operating pressures up to 5000 psi (350 bar), this valve accommodates substantial fluid dynamics within a compact design. It features extremely low leakage rates, with maximum leakage specified at less than 1 drop per minute (0.07 cc/min), ensuring minimal loss and optimal efficiency in operation. The construction of the CXEDLZV incorporates Sun's floating style, which minimizes potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining. This design enhances longevity and reliability under varied operational conditions. The valve also supports installation requirements with a specified torque range of 45 - 50 lbf\u00b7ft (61 - 68 Nm) and comes equipped with a Viton seal kit for enhanced performance under diverse environmental conditions. Overall, the Sun Hydraulics CXEDLZV check valve is an integral component for hydraulic systems needing precise backflow prevention and operational reliability, suitable for applications where fluid control and integrity are paramount.
The Sun Hydraulics CXEDLZV (CXEDLZV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model is distinguished by its free flow from the inlet port 2 to the outlet port 1, while effectively blocking flow in the reverse direction. The CXEDLZV is particularly useful as a circuit saver in systems where manifold drillings may be incorrect, offering an efficient solution without the need for extensive rework. With a capacity of 30 gpm (120 L/min) and maximum operating pressures up to 5000 psi (350 bar), this valve accommodates substantial fluid dynamics within a compact design. It features extremely low leakage rates, with maximum leakage specified at less than 1 drop per minute (0.07 cc/min), ensuring minimal loss and optimal efficiency in operation. The construction of the CXEDLZV incorporates Sun's floating style, which minimizes potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining. This design enhances longevity and reliability under varied operational conditions. The valve also supports installation requirements with a specified torque range of 45 - 50 lbf\u00b7ft (61 - 68 Nm) and comes equipped with a Viton seal kit for enhanced performance under diverse environmental conditions. Overall, the Sun Hydraulics CXEDLZV check valve is an integral component for hydraulic systems needing precise backflow prevention and operational reliability, suitable for applications where fluid control and integrity are paramount.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-203-006 |
