SUN HYDRAULICS
CXAAXZE
$152.40 USD
Tags:
- SUN HYDRAULICS
- Material:CXAAXZE
- Model:CXAA-XZE
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXAAXZE (CXAAXZE) is a robust check valve designed for hydraulic applications demanding reliable, one-way flow control and minimal leakage. This model is characterized by its free-flow feature from inlet port 1 to outlet port 2, while effectively blocking flow in the reverse direction. The CXAAXZE is engineered to operate under high pressures up to 5000 psi (350 bar) at both ports, making it suitable for high-pressure systems. It showcases an exceptionally low leakage rate of less than one drop per minute (0.07 cc/min), ensuring efficient system performance with minimal fluid loss. This valve incorporates Sun Hydraulics' floating style construction which minimizes the risk of internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. This design enhances the durability and reliability of the valve under various installation conditions. The CXAAXZE is designed for use with phosphate ester fluids, equipped with EPDM seals specifically chosen for their compatibility with such fluids; however, these seals are not suitable for contact with petroleum-based fluids, greases, and lubricants as exposure can lead to damage. With a capacity of 5 gpm (20 L/min) and a modest weight of 0.10 lb (0.5 kg), this model is compact yet capable of meeting the demands of a variety of hydraulic circuits. Installation specifications include a valve hex size of 7/8 in (22.2 mm) and an installation torque range of 20 - 25 lbf\u00b7ft (27 - 33 Nm), allowing for straightforward integration into existing systems without extensive modifications. The CXAAXZE is an essential component for applications requiring precise fluid control and robust performance in challenging environments.
The Sun Hydraulics CXAAXZE (CXAAXZE) is a robust check valve designed for hydraulic applications demanding reliable, one-way flow control and minimal leakage. This model is characterized by its free-flow feature from inlet port 1 to outlet port 2, while effectively blocking flow in the reverse direction. The CXAAXZE is engineered to operate under high pressures up to 5000 psi (350 bar) at both ports, making it suitable for high-pressure systems. It showcases an exceptionally low leakage rate of less than one drop per minute (0.07 cc/min), ensuring efficient system performance with minimal fluid loss. This valve incorporates Sun Hydraulics' floating style construction which minimizes the risk of internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. This design enhances the durability and reliability of the valve under various installation conditions. The CXAAXZE is designed for use with phosphate ester fluids, equipped with EPDM seals specifically chosen for their compatibility with such fluids; however, these seals are not suitable for contact with petroleum-based fluids, greases, and lubricants as exposure can lead to damage. With a capacity of 5 gpm (20 L/min) and a modest weight of 0.10 lb (0.5 kg), this model is compact yet capable of meeting the demands of a variety of hydraulic circuits. Installation specifications include a valve hex size of 7/8 in (22.2 mm) and an installation torque range of 20 - 25 lbf\u00b7ft (27 - 33 Nm), allowing for straightforward integration into existing systems without extensive modifications. The CXAAXZE is an essential component for applications requiring precise fluid control and robust performance in challenging environments.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-8A |
| Series | P |
| Capacity | 5 gpm20 L/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 20 - 25 lbf ft27 - 33 Nm |
| Model Weight | .10 lb0,5 kg |
| Seal kit - Cartridge | Viton: 990-608-006 |
