SUN HYDRAULICS
ZKL
$121.20 USD
Tags:
- SUN HYDRAULICS
- Material:ZKL
- Summary:Manifold
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics ZKL (Material Number: ZKL) is a high-quality sandwich manifold designed for hydraulic systems. This component features an ISO 05 interface and is constructed with a robust 6061-T651 aluminum body, known for its excellent corrosion resistance and durability. The stack height of the manifold is .99 inches (25 mm), providing a compact solution for hydraulic applications. It includes tap-in ports for P, T, A, and B lines, all sized at SAE 4, allowing for seamless integration into existing hydraulic systems. The unique design of Sun's sandwich manifolds includes aesthetically pleasing and functionally beneficial boss profiles that aid in proper alignment during assembly. This manifold is specifically engineered to maintain dry sealing surfaces by preventing oil film formation under O-rings, minimizing the risk of fluid leakage. It's crucial to ensure that the assembly surfaces are free of burrs and flat to optimize sealing performance. Additionally, Sun Hydraulics' choice not to anodize their aluminum bodies helps maintain the integrity and fatigue life of the manifold under high-pressure conditions up to 3000 psi (210 bar). This product is suitable for various hydraulic applications where space efficiency and reliable performance are essential.
The Sun Hydraulics ZKL (Material Number: ZKL) is a high-quality sandwich manifold designed for hydraulic systems. This component features an ISO 05 interface and is constructed with a robust 6061-T651 aluminum body, known for its excellent corrosion resistance and durability. The stack height of the manifold is .99 inches (25 mm), providing a compact solution for hydraulic applications. It includes tap-in ports for P, T, A, and B lines, all sized at SAE 4, allowing for seamless integration into existing hydraulic systems. The unique design of Sun's sandwich manifolds includes aesthetically pleasing and functionally beneficial boss profiles that aid in proper alignment during assembly. This manifold is specifically engineered to maintain dry sealing surfaces by preventing oil film formation under O-rings, minimizing the risk of fluid leakage. It's crucial to ensure that the assembly surfaces are free of burrs and flat to optimize sealing performance. Additionally, Sun Hydraulics' choice not to anodize their aluminum bodies helps maintain the integrity and fatigue life of the manifold under high-pressure conditions up to 3000 psi (210 bar). This product is suitable for various hydraulic applications where space efficiency and reliable performance are essential.
Body Type | SandwichSandwich |
Interface | ISO 05ISO 05 |
Body Features | Tap in manifold - P,T,A and BTap in manifold - P,T,A and B |
Stack Height | .99 in.25 mm |
Open Cavities | 00 |
Port Size | SAE 4SAE 4 |
