SUN HYDRAULICS
X4N

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics X4N (Material Number: X4N) is a line mount manifold specifically designed for hydraulic systems requiring a banjo bolt interface. This model features a direct mount body type, allowing for efficient integration into existing hydraulic setups. It is equipped with a T-5A cavity and has a port size of 3/4 BSPP, ensuring compatibility with various hydraulic components. The banjo bolt installation torque ranges from 170 lb. ft. to 185 lb. ft. (230 Nm to 250 Nm), and it requires a hex size of 1.42 for secure assembly. Constructed from 6061-T651 aluminum, the X4N manifold offers excellent corrosion resistance and durability, making it suitable for demanding environments where exposure to corrosive elements might be a concern. Despite its robust construction, this material choice ensures that the manifold remains relatively lightweight and cost-effective compared to other stronger but more expensive alloys like 2024. This manifold is not anodized, which helps maintain its cost-effectiveness and logistical efficiency during production while also preserving its fatigue life by avoiding the brittle surface layer that anodizing can introduce. The X4N is designed to handle pressures up to 3000 psi (210 bar), aligning with the limitations of aluminum manifolds. Ideal for high-flow valve applications, the Sun Hydraulics X4N provides reliable performance in hydraulic circuits requiring precise control and efficient fluid management. Its design facilitates quick installation and maintenance, making it an optimal choice for systems where downtime needs to be minimized.
