SUN HYDRAULICS
VZL

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics VZL (VZL) is a motor mount manifold specifically designed to facilitate the control and protection of hydraulic motors. This model is compatible with Eaton Char-Lynn 2000 series motors, offering a cross-port design that enhances fluid flow efficiency. Constructed from 6061-T651 aluminum, this manifold is known for its strength and excellent corrosion resistance, making it suitable for various environments without the need for anodizing. The manifold features a mounting hole diameter of 0.41 inches (10.4 mm) and is designed with three mounting holes that go through the body for secure attachment. It includes two open cavities and utilizes a T-10A cavity type, with port sizes set at 1/2 NPTF, ensuring compatibility with standard hydraulic systems. The VZL model is engineered to withstand maximum system pressures up to 3000 psi (210 bar), which aligns with the capabilities of aluminum manifolds in general. This ensures reliable performance under demanding conditions while maintaining safety standards. The manifold's design allows it to be integrated seamlessly into hydraulic systems where motor protection and efficient fluid management are critical. With its robust construction and thoughtful design features, the Sun Hydraulics VZL manifold provides an effective solution for managing hydraulic motor operations in various applications requiring precise control and durability.
