SUN HYDRAULICS
VRX

$986.60 USD

Tags:

SUN HYDRAULICS
Material:VRX
Summary:Manifold

Quantity in stock: 0

Note: Sales tax, and shipping will be calculated at checkout.

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics VRX (VRX) is a robust manifold designed to support hydraulic applications with its 4-station, parallel circuit configuration featuring a relief cavity. Constructed from 6061-T651 aluminum, this manifold offers excellent corrosion resistance and durability under various environmental conditions. The VRX model is specifically tailored for ISO 05 XY Euro interfaces and includes open cavities T3A, making it versatile for different hydraulic system configurations. It features a port size of 3/4 BSPP, ensuring compatibility with standard hydraulic fittings. The manifold's design does not include anodizing, which helps maintain cost-effectiveness and avoids potential issues such as increased breakaway torque and reduced fatigue life often associated with anodized surfaces. This makes the Sun Hydraulics VRX an ideal choice for those seeking reliable performance without the additional complexities of anodization. Please note that while the manifold can handle pressures up to 3000 psi (210 bar), it is essential to consider the maximum system pressure in relation to the material and port size to ensure optimal performance and safety in operation.

Description

Body Type	Bar ManifoldBar Manifold
Interface	ISO 05 - X&Y (Euro)ISO 05 - X&Y (Euro)
Body Features	4 Station, Parallel circuit with relief cavity4 Station, Parallel circuit with relief cavity
Open Cavities	11
Cavity	T-3A
Port Size	3/4" BSPP3/4" BSPP

Show FAQ

Why does Sun use 6061 aluminum?	6061-T651 is relatively strong, relatively inexpensive, difficult to machine, readily available in all shapes and sizes and very corrosion resistant. 2024 is stronger and machines beautifully, but is expensive and falls to pieces in a corrosive environment.
Why doesn't Sun anodize their aluminum bodies?	Reasons to anodize: To increase corrosion resistance. Sun uses 6061-T651 aluminum. It is one of the most corrosion resistant aluminum alloys there is. Whether or not anodizing improves the corrosion resistance of 6061 aluminum is debatable. We have yet to have a manifold returned because of corrosion. Appearance (color). The 2 colors that would appeal to Sun would be blue or black. Unfortunately these are the colors that are hardest to do consistently. To provide a hard wear surface. Sun does not make parts-in-body valves. The manifold is just plumbing. We don't need a wear surface. Because everyone else does it. Bad reason. Reasons to not anodize: Cost. It's another process. Logistics. When you make tens of thousands of manifolds a month and you anodize hundreds, it's a problem. Consistency. See above. Stamping. After a body is anodized you cannot do any more stamping without making a mess.Inspection. Have you ever tried to look for burrs in a black anodized body? It's the old blackboard factory at night scenario. Torque. You will experience an increase in breakaway torque when removing items from an anodized manifold. Fatigue life. This is the best reason to not anodize. Fatigue failure is a very complex phenomenon. What it takes to initiate a crack is difficult to predict. What it takes to propagate a crack is readily defined. Anodizing produces a very thin, very hard, and very brittle surface on aluminum. The first time you pressurize an anodized aluminum manifold you have initiated fatigue cracks. Whether or not the stress is enough to propagate the cracks is a matter of pressure and manifold geometry. Anodizing an aluminum manifold grossly reduces the fatigue life by anywhere from 20% to 50%.
How big is a drop of hydraulic oil?	There are exactly 250 Sun drops in a cubic inch or 15 in a cc.

Additional Resources

Notes:

For mounting bracket information, see catalog or drawing 991-021-***
Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
