SUN HYDRAULICS
VRV/V
$576.50 USD
Tags:
- SUN HYDRAULICS
- Material:VRV/V
- Summary:Manifold
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics VRV/V (Material Number: VRV/V) is a robust and versatile manifold designed for hydraulic systems. This product features a 2-station, parallel circuit with a relief cavity, enhancing its capability to manage fluid flow efficiently. It is constructed using 6061-T651 aluminum, known for its corrosion resistance and durability, making it suitable for various hydraulic applications. The manifold adheres to the ISO 05 XY Euro interface standard and includes open cavities designated as T-3A. It accommodates port sizes of 3/4 BSPP, allowing for secure connections in hydraulic circuits. With a focus on performance and reliability, the manifold is designed to withstand pressures up to 3000 psi (210 bar), ensuring safe operation within specified limits. This product is ideal for applications requiring precise fluid control and distribution in complex hydraulic systems.
The Sun Hydraulics VRV/V (Material Number: VRV/V) is a robust and versatile manifold designed for hydraulic systems. This product features a 2-station, parallel circuit with a relief cavity, enhancing its capability to manage fluid flow efficiently. It is constructed using 6061-T651 aluminum, known for its corrosion resistance and durability, making it suitable for various hydraulic applications. The manifold adheres to the ISO 05 XY Euro interface standard and includes open cavities designated as T-3A. It accommodates port sizes of 3/4 BSPP, allowing for secure connections in hydraulic circuits. With a focus on performance and reliability, the manifold is designed to withstand pressures up to 3000 psi (210 bar), ensuring safe operation within specified limits. This product is ideal for applications requiring precise fluid control and distribution in complex hydraulic systems.
Body Type | Bar ManifoldBar Manifold |
Interface | ISO 05 - X&Y (Euro)ISO 05 - X&Y (Euro) |
Body Features | 2 Station, Parallel circuit with relief cavity2 Station, Parallel circuit with relief cavity |
Open Cavities | 11 |
Cavity | T-3A |
Port Size | 3/4" BSPP3/4" BSPP |
Show FAQ
Additional Resources
- QuickDesign with SmartConnect Offers Drag-and-Drop Schematic Tool
- Manufacturing Sun Cartridge Cavities
- Sun Model Code Explanation; 999-901-334
- Custom Integrated Packages from Sun
- Fluid and Temperature Recommendations
- QuickDesign & SunDesign: Sun's 3- & 5-Axis Solutions
- Manifolds: Materials of Construction
- Sun's Floating Style Screw-In Cartridge
Notes:
- For mounting bracket information, see catalog or drawing 991-021-***
- Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
