SUN HYDRAULICS
U2K/W

$528.00 USD

Tags:

SUN HYDRAULICS
Material:U2K/W
Summary:Manifold

Quantity in stock: 0

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics U2K/W (Material Number: U2K/W) is a line mount manifold designed for high-flow hydraulic systems. It features a sandwich mount through port and is compatible with 1.25 SAE C62 interface standards. The body type is specifically engineered for line mounting, providing flexibility in system design and integration. This manifold includes eight mounting holes with a thread size of M14x2,0 6H metric models, each having a depth of 1.00 inch or 25.4 mm, ensuring secure installation. The open cavities are designed to accommodate T16A cavity valves, while the port size is specified as 1 14 Code 62. Constructed from 6061T651 aluminum, the manifold offers exceptional corrosion resistance and durability without the need for anodizing, which could negatively impact fatigue life by introducing stress cracks under pressure. This material choice ensures that the manifold maintains structural integrity under operating pressures up to 3000 psi (210 bar), making it suitable for various demanding applications where reliability is paramount. The U2K/W model's robust design and compatibility with standard line mount configurations make it an ideal choice for applications requiring efficient fluid control and management in hydraulic systems. Its simple yet effective construction allows for easy integration into existing setups while providing dependable performance in controlling fluid flow within high-pressure environments.

Description

Body Type	Line mountLine mount
Interface	1.25 SAE C621.25 SAE C62
Body Features	Sandwich mount through portSandwich mount through port
Mounting Hole Diameter	.59 in. (metric models)15,0 mm (metric models)
Mounting Hole Thread	M14x2,0 - 6H (metric models)M14x2,0 - 6H (metric models)
Mounting Hole Depth	1.00 in.25,4 mm
Mounting Hole Quantity	88
Open Cavities	11
Cavity	T-16A
Port Size	1 1/4" Code 621 1/4" Code 62

Show FAQ

How big is a drop of hydraulic oil?	There are exactly 250 Sun drops in a cubic inch or 15 in a cc.
Why does Sun use 6061 aluminum?	6061-T651 is relatively strong, relatively inexpensive, difficult to machine, readily available in all shapes and sizes and very corrosion resistant. 2024 is stronger and machines beautifully, but is expensive and falls to pieces in a corrosive environment.
Why doesn't Sun anodize their aluminum bodies?	Reasons to anodize: To increase corrosion resistance. Sun uses 6061-T651 aluminum. It is one of the most corrosion resistant aluminum alloys there is. Whether or not anodizing improves the corrosion resistance of 6061 aluminum is debatable. We have yet to have a manifold returned because of corrosion. Appearance (color). The 2 colors that would appeal to Sun would be blue or black. Unfortunately these are the colors that are hardest to do consistently. To provide a hard wear surface. Sun does not make parts-in-body valves. The manifold is just plumbing. We don't need a wear surface. Because everyone else does it. Bad reason. Reasons to not anodize: Cost. It's another process. Logistics. When you make tens of thousands of manifolds a month and you anodize hundreds, it's a problem. Consistency. See above. Stamping. After a body is anodized you cannot do any more stamping without making a mess.Inspection. Have you ever tried to look for burrs in a black anodized body? It's the old blackboard factory at night scenario. Torque. You will experience an increase in breakaway torque when removing items from an anodized manifold. Fatigue life. This is the best reason to not anodize. Fatigue failure is a very complex phenomenon. What it takes to initiate a crack is difficult to predict. What it takes to propagate a crack is readily defined. Anodizing produces a very thin, very hard, and very brittle surface on aluminum. The first time you pressurize an anodized aluminum manifold you have initiated fatigue cracks. Whether or not the stress is enough to propagate the cracks is a matter of pressure and manifold geometry. Anodizing an aluminum manifold grossly reduces the fatigue life by anywhere from 20% to 50%.

Additional Resources

Notes:

Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
