SUN HYDRAULICS
U2K/M
$295.10 USD
Tags:
- SUN HYDRAULICS
- Material:U2K/M
- Summary:Manifold
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics U2K/M (U2K/M) is a robust line mount manifold specifically designed to accommodate high flow valves in hydraulic systems. It features an interface of 1.25 SAE C62, allowing it to be easily integrated into existing systems with similar specifications. The manifold is constructed with a sandwich mount through port design, which aids in efficient fluid transfer and system integration. With a mounting hole diameter of .59 inches (15.0 mm for metric models) and a thread specification of M14x2,0 6H, this manifold ensures secure installation and reliable performance in demanding applications. It includes eight mounting holes with a depth of 1.00 inch (25.4 mm), providing sturdy support for the hydraulic components. The U2K/M model is equipped with open cavities that are compatible with T16A cartridges, making it versatile for various hydraulic configurations and applications. The port size of 1 14 Code 62 supports high-pressure operations while maintaining integrity under demanding conditions up to the maximum rated pressure of 3000 psi (210 bar). However, users must consider the system's maximum pressure as aluminum manifolds are not rated above this pressure threshold. This manifold is crafted from durable 6061T651 aluminum, known for its strength and corrosion resistance, ensuring longevity even in harsh environments without the need for anodizing. Its design serves as efficient plumbing within hydraulic circuits without requiring additional wear surfaces or anodizing processes, simplifying maintenance and reducing costs associated with anodized components. Overall, the Sun Hydraulics U2K/M line mount manifold offers reliable performance and adaptability for high flow hydraulic applications, providing engineers with a versatile solution for integrating various hydraulic cartridge valves into their systems efficiently.
The Sun Hydraulics U2K/M (U2K/M) is a robust line mount manifold specifically designed to accommodate high flow valves in hydraulic systems. It features an interface of 1.25 SAE C62, allowing it to be easily integrated into existing systems with similar specifications. The manifold is constructed with a sandwich mount through port design, which aids in efficient fluid transfer and system integration. With a mounting hole diameter of .59 inches (15.0 mm for metric models) and a thread specification of M14x2,0 6H, this manifold ensures secure installation and reliable performance in demanding applications. It includes eight mounting holes with a depth of 1.00 inch (25.4 mm), providing sturdy support for the hydraulic components. The U2K/M model is equipped with open cavities that are compatible with T16A cartridges, making it versatile for various hydraulic configurations and applications. The port size of 1 14 Code 62 supports high-pressure operations while maintaining integrity under demanding conditions up to the maximum rated pressure of 3000 psi (210 bar). However, users must consider the system's maximum pressure as aluminum manifolds are not rated above this pressure threshold. This manifold is crafted from durable 6061T651 aluminum, known for its strength and corrosion resistance, ensuring longevity even in harsh environments without the need for anodizing. Its design serves as efficient plumbing within hydraulic circuits without requiring additional wear surfaces or anodizing processes, simplifying maintenance and reducing costs associated with anodized components. Overall, the Sun Hydraulics U2K/M line mount manifold offers reliable performance and adaptability for high flow hydraulic applications, providing engineers with a versatile solution for integrating various hydraulic cartridge valves into their systems efficiently.
| Body Type | Line mountLine mount |
| Interface | 1.25 SAE C621.25 SAE C62 |
| Body Features | Sandwich mount through portSandwich mount through port |
| Mounting Hole Diameter | .59 in. (metric models)15,0 mm (metric models) |
| Mounting Hole Thread | M14x2,0 - 6H (metric models)M14x2,0 - 6H (metric models) |
| Mounting Hole Depth | 1.00 in.25,4 mm |
| Mounting Hole Quantity | 88 |
| Open Cavities | 11 |
| Cavity | T-16A |
| Port Size | 1 1/4" Code 621 1/4" Code 62 |
Show FAQ
Additional Resources
- Standard Line Mount Manifolds for High Flow Valves
- QuickDesign with SmartConnect Offers Drag-and-Drop Schematic Tool
- Manufacturing Sun Cartridge Cavities
- Sun Model Code Explanation; 999-901-334
- Custom Integrated Packages from Sun
- Fluid and Temperature Recommendations
- QuickDesign & SunDesign: Sun's 3- & 5-Axis Solutions
- Manifolds: Materials of Construction
- Sun's Floating Style Screw-In Cartridge
Notes:
- Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
