SUN HYDRAULICS
RVBBCQV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVBBCQV (Material Number: RVBBCQV) is a versatile three-port, normally closed modulating element with relief functionality, designed to provide two distinct functions when paired with an external orifice. This component acts primarily as a bypass compensator, regulating a priority flow into the circuit based on the external orifice specifications. Any input flow that surpasses the designated priority flow is redirected to the tank port 2. Furthermore, if the pressure at inlet port 1 escalates to meet the valve's preset level, it functions as a standard relief valve. The compensating pressure across all ranges is maintained at 50 psi (3.5 bar). The performance curve illustrates system pressure on the X-axis and the pressure differential generated by the valve across the control orifice on the Y-axis. These curves indicate various bypass flows, which are calculated as pump flow minus control flow; notably, control flow does not influence capacity and performance. This model features a cavity size of T-163A and belongs to Series 0 with a capacity of 5 gpm (20 L/min). It can handle a maximum operating pressure of up to 5000 psi (350 bar) with a typical response time of 10 ms. The maximum valve leakage at 110 SUS (24 cSt) is specified at 2 in\u00b3/min (30 cc/min) under conditions of 1000 psi (70 bar). Adjustment for increasing settings requires approximately five full clockwise turns. The valve hex size is measured at .34 inches (19.1 mm), and it requires an installation torque between 20 - 25 lbf ft (27 - 33 Nm). Additionally, this model weighs .30 lb (.15 kg) and utilizes Viton seal kits for optimal performance and durability in various applications.
