SUN HYDRAULICS
RPGEJAV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPGEJAV (RPGEJAV) is a fast-acting, pilot-operated, balanced piston relief cartridge designed to protect hydraulic components from pressure transients. This normally closed, pressure-limiting valve rapidly opens and closes, offering low pressure rise versus flow but sacrificing smoothness for speed. When the inlet port pressure reaches the valve setting, it begins to open to tank port 2, throttling flow to limit pressure increase. Notably, these valves are not suitable for load holding applications due to spool leakage. They are interchangeable with all 2-port relief cartridges of the same frame size and flow path and can handle maximum pressure at port 2, making them suitable for cross-port relief circuits. The main stage orifice is safeguarded by a 150-micron stainless steel screen. The RPGEJAV cartridge incorporates Sun's floating style construction to minimize internal part binding due to excessive installation torque or machining variations. It features a cavity size of T-3A and a series number of 2 with a capacity of up to 50 gpm (200 L/min). The factory pressure settings are established at 4 gpm (15 L/min), with a maximum operating pressure of 5000 psi (350 bar) and typical response time of about 2 milliseconds. Maximum valve leakage is recorded at 3 in\u00b3/min at 1000 psi (50 cc/min at 70 bar). The adjustment allows for five clockwise turns to increase setting, with specific torque requirements for installation and locknut adjustments. Cartridges configured with EPDM seals are intended for systems using phosphate ester fluids; exposure to petroleum-based fluids will damage these seals. The model weighs approximately .50 lb (.25 kg) and includes a Viton seal kit option under part number 990203006.
