SUN HYDRAULICS
RDBXXWV/AP

$236.60 USD

Tags:

SUN HYDRAULICS
Material:RDBXXWV/AP
Model:RDBX-XWV/AP
Summary:Cartridge

Quantity in stock: 0

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RDBXXWV/AP (RDBXXWV/AP) is a precision-engineered hydraulic relief valve designed for optimal pressure regulation in hydraulic systems. This model is built to fit the T-162A cavity and features a hex size of 3/4 inch (19.1 mm), with an installation torque requirement ranging from 20 to 25 lbf ft (27 to 33 Nm). The valve is equipped with a Viton seal kit, ensuring robust performance and reliability in various operating conditions. Known for its dirt tolerance and stability, this direct-acting relief valve is ideal for preventing overpressure scenarios in hydraulic circuits. Its design allows for quick response times, making it suitable for applications that demand rapid pressure adjustments. The valve's construction supports ease of maintenance and long-term durability, contributing to reduced downtime and operational efficiency.

Description

Cavity	T-162A
Series	0
Valve Hex Size	3/4 in.19,1 mm
Valve Installation Torque	20 - 25 lbf ft27 - 33 Nm
Seal kit - Cartridge	Viton: 990-162-006

Show FAQ

What are the tolerances on pressure settings for Sun's pressure control valves?	Pressure setting tolerances are listed in our Performance Data page. A link to this page can also be found in the Additional Resources tab of the applicable product page.
How big is a drop of hydraulic oil?	There are exactly 250 Sun drops in a cubic inch or 15 in a cc.
Can I use a kick-down relief for my system relief?	Maybe not. We build in a good amount of overlap in the kick-down reliefs to prevent false tripping. This means they are not as fast as our standard pilot-operated reliefs. A direct-acting relief valve set just above the kick-down relief valve would be good insurance.
Direct acting or pilot operated - what do I use?	Direct-acting valves are used to prevent over pressure, and pilot-operated valves are used to regulate pressure. If you are unsure, use a direct-acting valve. Sun's direct acting valves are very fast, dirt tolerant, stable, and robust. Sun's pilot-operated valves are moderately fast, they have a low pressure rise vs. flow curve, and they are easy to adjust.
Where would I use a kick-down relief?	One graphic example is on a portable grain auger for silos. When the farmer gets caught in the auger the kick-down relief trips and allows him to escape.
