SUN HYDRAULICS
QMN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics QMN (Material Number: QMN) is a line mount manifold designed for hydraulic systems requiring a ninety-degree body configuration. This model features two mounting holes with a diameter of 0.42 inches (10.7 mm) and allows for through-hole depth installation, ensuring secure and stable mounting with two holes provided. It includes one open cavity designed according to the T-34A specification, making it compatible with various hydraulic components that utilize this cavity type. The manifold accommodates SAE 20 port sizes, facilitating efficient fluid transfer in high-flow applications. Constructed from 6061-T651 aluminum, the QMN manifold offers excellent corrosion resistance and durability without the need for anodizing, which helps maintain its structural integrity and extends its fatigue life. The material choice ensures that the manifold can withstand harsh environments while remaining cost-effective and easy to machine. However, users should note that this aluminum manifold is not rated for pressures exceeding 3000 psi (210 bar), regardless of port size. The QMN's design makes it ideal for use in hydraulic systems where space constraints require compact solutions without sacrificing performance or reliability. Its robust construction and compatibility with standard Sun cartridge cavities provide flexibility in system design, allowing engineers to integrate it seamlessly into existing setups or new projects requiring efficient fluid management solutions.
