SUN HYDRAULICS
FREAKAN
$198.80 USD
Tags:
- SUN HYDRAULICS
- Material:FREAKAN
- Model:FREA-KAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FREAKAN (FREAKAN) is a bypass-restrictive, fixed-orifice, priority flow control valve designed to manage hydraulic flow efficiently. This valve accepts input flow at port 1 and directs it to satisfy the priority flow demand at port 3. If the input surpasses the required priority flow, the surplus is redirected through port 2 for use in secondary circuits. Users must specify a desired flow rating, which will be factory set with a precision of within 10% of the requested value. The maximum pressure at port 3 is advised not to exceed 3000 psi (210 bar). An adjustable control option allows for up to a 22% variation from the preset factory flow, adjustable via three turns of an internal hex screw. With a maximum capacity of 25 gpm (95 L/min) and an operating pressure up to 5000 psi (350 bar), this valve can handle significant hydraulic demands. It features Sun's floating style construction, which reduces the chance of internal binding due to excessive torque or machining discrepancies during installation. The sharp-edged orifice design helps maintain consistent flow despite viscosity changes in hydraulic fluids. The FREAKAN model is equipped with a T17A cavity and has dimensions suited for robust applications: a valve hex size of 1-1/4 inches (31.8 mm) and installation torque between 150-160 lbf ft (203-217 Nm). The adjustment screw requires a 5/32 inch (4 mm) internal hex size, while the locknut needs a 9/16 inch (15 mm) size with torque specifications of 80-90 lbf in (9-10 Nm). With its capacity for handling high pressures and flows efficiently, this valve is ideal for systems requiring precise priority flow management with adaptable secondary circuit capabilities.
The Sun Hydraulics FREAKAN (FREAKAN) is a bypass-restrictive, fixed-orifice, priority flow control valve designed to manage hydraulic flow efficiently. This valve accepts input flow at port 1 and directs it to satisfy the priority flow demand at port 3. If the input surpasses the required priority flow, the surplus is redirected through port 2 for use in secondary circuits. Users must specify a desired flow rating, which will be factory set with a precision of within 10% of the requested value. The maximum pressure at port 3 is advised not to exceed 3000 psi (210 bar). An adjustable control option allows for up to a 22% variation from the preset factory flow, adjustable via three turns of an internal hex screw. With a maximum capacity of 25 gpm (95 L/min) and an operating pressure up to 5000 psi (350 bar), this valve can handle significant hydraulic demands. It features Sun's floating style construction, which reduces the chance of internal binding due to excessive torque or machining discrepancies during installation. The sharp-edged orifice design helps maintain consistent flow despite viscosity changes in hydraulic fluids. The FREAKAN model is equipped with a T17A cavity and has dimensions suited for robust applications: a valve hex size of 1-1/4 inches (31.8 mm) and installation torque between 150-160 lbf ft (203-217 Nm). The adjustment screw requires a 5/32 inch (4 mm) internal hex size, while the locknut needs a 9/16 inch (15 mm) size with torque specifications of 80-90 lbf in (9-10 Nm). With its capacity for handling high pressures and flows efficiently, this valve is ideal for systems requiring precise priority flow management with adaptable secondary circuit capabilities.
Bypass/restrictive, fixed-orifice, priority flow controls take an input flow at port 1 and use it to satisfy the priority flow at port 3. If the input flow exceeds the priority flow requirement, the excess is bypassed out port 2. The bypass flow may be used in a secondary circuit.
- Customer must specify a flow rating. Factory set flow ratings are within +/- 10% of the requested setting.
- Maximum pressure at port 3 should be limited to 3000 psi (210 bar).
- A tuneable adjustment control option provides up to +/- 22% variation from the nominal factory pre-set flow. Adjustment is done with +/- 3 turns of the adjust screw. Screw in (CW) to increase flow.
- Both priority and bypass flow are usable up to the system operating pressure.
- Priority remains relatively constant regardless of variation in input flow.
- Bypass flow is not available until priority flow requirements are satisfied.
- Pressure at the bypass port (port 2) may exceed pressure at the priority port (port 3).
- The sharp-edged orifice design minimizes flow variations due to viscosity changes.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-17A |
| Series | 3 |
| Capacity | 25 gpm95 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Input Flow | 60 gpm240 L/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | 1.25 lb0,60 kg |
| Seal kit - Cartridge | Viton: 990-017-006 |
