SUN HYDRAULICS
FCEBXBN
$207.90 USD
Tags:
- SUN HYDRAULICS
- Material:FCEBXBN
- Model:FCEB-XBN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FCEBXBN (FCEBXBN) is a fixed orifice, pressure-compensated flow control valve designed to deliver precise flow regulation for both meter-in and meter-out applications, accommodating wide pressure fluctuations. This model features an integral high-capacity check valve that allows unrestricted reverse flow from port 2 to port 1. The flow setting is user-specified and factory-set with a precision of within 10% of the requested setting. Its sharp-edged orifice design minimizes variations due to viscosity changes, ensuring consistent performance. This cartridge is part of the T16A cavity series 3 and has a capacity of up to 25 gpm (95 L/min) with a maximum operating pressure of 5000 psi (350 bar). The valve's hex size is 1 1/4 inches (31.8 mm), and it requires an installation torque between 150-160 lbf ft (203-217 Nm). For adjustment, the internal hex size is 5/32 inches (4 mm), while the locknut hex size is 9/16 inches (15 mm) with a torque requirement of 80-90 lbf in (9-10 Nm). Weighing approximately 1.00 lb (0.45 kg), this model incorporates Sun's floating style construction, reducing the risk of internal binding due to excessive torque or machining variations. Additionally, it offers corrosion-resistant options identified by suffixes AP or LH for stainless steel or zinc-nickel plated components respectively. The tuneable control option provides a \u00b122% variation from the nominal factory preset flow, allowing users to adjust by turning clockwise to increase flow. This product is suitable for use in various environments where precision and reliability in hydraulic flow control are essential.
The Sun Hydraulics FCEBXBN (FCEBXBN) is a fixed orifice, pressure-compensated flow control valve designed to deliver precise flow regulation for both meter-in and meter-out applications, accommodating wide pressure fluctuations. This model features an integral high-capacity check valve that allows unrestricted reverse flow from port 2 to port 1. The flow setting is user-specified and factory-set with a precision of within 10% of the requested setting. Its sharp-edged orifice design minimizes variations due to viscosity changes, ensuring consistent performance. This cartridge is part of the T16A cavity series 3 and has a capacity of up to 25 gpm (95 L/min) with a maximum operating pressure of 5000 psi (350 bar). The valve's hex size is 1 1/4 inches (31.8 mm), and it requires an installation torque between 150-160 lbf ft (203-217 Nm). For adjustment, the internal hex size is 5/32 inches (4 mm), while the locknut hex size is 9/16 inches (15 mm) with a torque requirement of 80-90 lbf in (9-10 Nm). Weighing approximately 1.00 lb (0.45 kg), this model incorporates Sun's floating style construction, reducing the risk of internal binding due to excessive torque or machining variations. Additionally, it offers corrosion-resistant options identified by suffixes AP or LH for stainless steel or zinc-nickel plated components respectively. The tuneable control option provides a \u00b122% variation from the nominal factory preset flow, allowing users to adjust by turning clockwise to increase flow. This product is suitable for use in various environments where precision and reliability in hydraulic flow control are essential.
Fixed-orifice, pressure-compensated flow controls with reverse-flow check provide precise flow regulation for meter-in or meter-out applications where there may be wide pressure fluctuations. An integral high-capacity check valve provides unrestricted flow from port 2 to port 1. The flow setting is specified by the user and is set at the factory.
- Customer must specify a flow rating. Factory set flow ratings are within +/- 10% of the requested setting.
- The sharp-edged orifice design minimizes flow variations due to viscosity changes.
- All 2-port flow control cartridges are physically and functionally interchangeable (i.e. same flow path, same cavity for a given frame size). However, cartridge extension dimensions from the mounting surface may vary.
- The tuneable control option provides +/- 22% variation from the nominal factory pre-set flow. Turn the adjustment clockwise to increase.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP for external stainless steel components, or /LH for external zinc-nickel plated components. See the CONFIGURATION section for all options. For further details, please see the Materials of Construction page located under TECH RESOURCES.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 25 gpm95 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | 1.00 lb0,45 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
