SUN HYDRAULICS
E4U

$97.30 USD

Tags:

SUN HYDRAULICS
Material:E4U
Summary:Manifold

Quantity in stock: 0

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics E4U (Material Number: E4U) is a line mount manifold designed for hydraulic systems, featuring a ninety-degree configuration with a reverse flow check and reducing capability. This model is crafted from 6061T651 aluminum, known for its excellent corrosion resistance and structural integrity. The manifold has an interface without mounting holes, making it versatile for various hydraulic applications requiring efficient flow control. It includes two mounting holes with a diameter of .34 inches (8.6 mm) and a depth that goes through the entire body, allowing secure attachment in system setups. The E4U model accommodates open cavities with one T-11A cavity and ports sized at 3/8 BSPP, ensuring compatibility with standard hydraulic components. This manifold is engineered to withstand pressures up to 3000 psi (210 bar), suitable for medium-pressure hydraulic applications. Its robust design supports reliable performance in systems where precise flow management is crucial. The use of high-grade aluminum not only enhances the durability of the E4U but also ensures it remains lightweight and easy to install within complex assemblies. Sun Hydraulics' decision not to anodize this manifold stems from considerations around cost efficiency, logistics, and maintaining the material's fatigue life. Anodizing can introduce brittleness that may reduce the component's longevity under stress conditions typical in hydraulic environments. Therefore, this product offers an optimal balance between strength, resistance to environmental factors, and cost-effectiveness for users seeking dependable performance in their hydraulic systems without additional surface treatments.

Description

Body Type	Line mountLine mount
Interface	NoneNone
Body Features	Ninety degree with reverse flow check - reducingNinety degree with reverse flow check - reducing
Mounting Hole Diameter	.34 in.8.6 mm
Mounting Hole Depth	ThroughThrough
Mounting Hole Quantity	22
Open Cavities	11
Cavity	T-11A
Port Size	3/8" BSPP3/8" BSPP

Show FAQ

Why doesn't Sun anodize their aluminum bodies?	Reasons to anodize: To increase corrosion resistance. Sun uses 6061-T651 aluminum. It is one of the most corrosion resistant aluminum alloys there is. Whether or not anodizing improves the corrosion resistance of 6061 aluminum is debatable. We have yet to have a manifold returned because of corrosion. Appearance (color). The 2 colors that would appeal to Sun would be blue or black. Unfortunately these are the colors that are hardest to do consistently. To provide a hard wear surface. Sun does not make parts-in-body valves. The manifold is just plumbing. We don't need a wear surface. Because everyone else does it. Bad reason. Reasons to not anodize: Cost. It's another process. Logistics. When you make tens of thousands of manifolds a month and you anodize hundreds, it's a problem. Consistency. See above. Stamping. After a body is anodized you cannot do any more stamping without making a mess.Inspection. Have you ever tried to look for burrs in a black anodized body? It's the old blackboard factory at night scenario. Torque. You will experience an increase in breakaway torque when removing items from an anodized manifold. Fatigue life. This is the best reason to not anodize. Fatigue failure is a very complex phenomenon. What it takes to initiate a crack is difficult to predict. What it takes to propagate a crack is readily defined. Anodizing produces a very thin, very hard, and very brittle surface on aluminum. The first time you pressurize an anodized aluminum manifold you have initiated fatigue cracks. Whether or not the stress is enough to propagate the cracks is a matter of pressure and manifold geometry. Anodizing an aluminum manifold grossly reduces the fatigue life by anywhere from 20% to 50%.
How big is a drop of hydraulic oil?	There are exactly 250 Sun drops in a cubic inch or 15 in a cc.
Why does Sun use 6061 aluminum?	6061-T651 is relatively strong, relatively inexpensive, difficult to machine, readily available in all shapes and sizes and very corrosion resistant. 2024 is stronger and machines beautifully, but is expensive and falls to pieces in a corrosive environment.

Additional Resources

Notes:

Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
