SUN HYDRAULICS
E4B

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics E4B (Material Number: E4B) is a line mount hydraulic manifold designed for efficient fluid control in hydraulic systems. This manifold features a ninety-degree configuration with a reverse flow check, enhancing its capability to manage fluid direction and pressure within the system. It is constructed from 6061-T651 aluminum, known for its high corrosion resistance and durability, making it suitable for various demanding environments. The E4B model includes two mounting holes with a diameter of .34 inches (8.6 mm), facilitating secure installation in hydraulic setups, and it accommodates one open cavity with a T-11A cavity type. The port size is 3/8 NPTF, ensuring compatibility with standard hydraulic fittings. This manifold's design prioritizes functionality without unnecessary processes such as anodizing, which can increase costs and affect fatigue life negatively. The choice of material and manufacturing processes reflects an emphasis on maintaining structural integrity under operational pressures up to 3000 psi (210 bar), making it reliable for applications that require robust performance without compromising on safety standards. Its construction allows for easy integration into existing systems while maintaining high efficiency in controlling fluid dynamics.
