SUN HYDRAULICS
DCEBDHN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCEBDHN (DCEBDHN) is a high-performance two-position, detented, 4-way directional cartridge valve. This robust model features six ports with a capacity to handle pressures up to 5000 psi (350 bar). The DCEBDHN can be customized with up to three different spool options depending on the specific application needs. Each port, including the x and y pilot ports (port 5 and port 6), supports the maximum operational pressure, enhancing the valve's versatility in various hydraulic systems. Designed for durability and reliability, the DCEBDHN incorporates a hardened spool and sleeve which not only ensure low leakage rates but also provide excellent wear characteristics. This model benefits from Sun Hydraulics' floating style construction which minimizes internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. With a flow capacity ranging between 40 to 60 gpm (160 to 240 L/min), this valve is suitable for substantial hydraulic flows. It maintains maximum valve leakage at an efficient rate of 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). The pilot volume displacement is .34 in\u00b3 (5.6 cc), and it requires an installation torque of 150 -160 lbf ft (203 -217 Nm). The model weighs approximately 1.80 lbs (0.80 kg) and uses a Viton seal kit for enhanced performance under varying conditions. The hex size for valve installation measures at 1\u00bc inches (31.8 mm), ensuring compatibility with standard tools for easy installation and maintenance.
