SUN HYDRAULICS
DCCADAN
$181.70 USD
Tags:
- SUN HYDRAULICS
- Material:DCCADAN
- Model:DCCA-DAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCCADAN (DCCADAN) is a high-performance directional control valve designed for advanced hydraulic systems requiring precise control and reliability. This three-position, 4-way directional cartridge features a spring-centered mechanism, offering versatility through 10 different spool options to cater to various operational needs. Each valve is engineered with a 6-port configuration where the supply port is designated as port 1, and all ports are capable of accommodating pressures up to 5000 psi (350 bar). The DCCADAN model ensures minimal leakage and optimal performance under high-pressure conditions, with maximum valve leakage specified at 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). It also supports a flow capacity ranging from 7 to 10 gpm (28 to 40 L/min), making it suitable for a broad range of flow rates in hydraulic circuits. The minimum pilot pressure required to shift the valve is set at 175 psi (12 bar), ensuring responsive and efficient operation. Constructed with hardened spool and sleeve, the DCCADAN guarantees low spool leakage rates and exceptional wear characteristics, enhancing the longevity and durability of the system. Additionally, Sun Hydraulics incorporates their unique floating style construction in this model, which reduces risks related to internal parts binding due to excessive installation torque or cavity/cartridge machining variations. This feature ensures consistent performance even under varying installation conditions. The valve's specifications also include a pilot volume displacement of .02 in\u00b3 (0.33 cc), hex size for installation at 7/8 in. (22.2 mm), and an installation torque range between 30-35 lbf\u00b7ft (41-47 Nm). Weighing just .40 lb (0.20 kg), the DCCADAN offers a compact yet robust solution for demanding hydraulic applications.
The Sun Hydraulics DCCADAN (DCCADAN) is a high-performance directional control valve designed for advanced hydraulic systems requiring precise control and reliability. This three-position, 4-way directional cartridge features a spring-centered mechanism, offering versatility through 10 different spool options to cater to various operational needs. Each valve is engineered with a 6-port configuration where the supply port is designated as port 1, and all ports are capable of accommodating pressures up to 5000 psi (350 bar). The DCCADAN model ensures minimal leakage and optimal performance under high-pressure conditions, with maximum valve leakage specified at 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). It also supports a flow capacity ranging from 7 to 10 gpm (28 to 40 L/min), making it suitable for a broad range of flow rates in hydraulic circuits. The minimum pilot pressure required to shift the valve is set at 175 psi (12 bar), ensuring responsive and efficient operation. Constructed with hardened spool and sleeve, the DCCADAN guarantees low spool leakage rates and exceptional wear characteristics, enhancing the longevity and durability of the system. Additionally, Sun Hydraulics incorporates their unique floating style construction in this model, which reduces risks related to internal parts binding due to excessive installation torque or cavity/cartridge machining variations. This feature ensures consistent performance even under varying installation conditions. The valve's specifications also include a pilot volume displacement of .02 in\u00b3 (0.33 cc), hex size for installation at 7/8 in. (22.2 mm), and an installation torque range between 30-35 lbf\u00b7ft (41-47 Nm). Weighing just .40 lb (0.20 kg), the DCCADAN offers a compact yet robust solution for demanding hydraulic applications.
Three-position, 4-way directional cartridges are spring-centered, 6-port directional valves that can be configured from a choice of 10 different spool options. The supply port is port 1 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-61A |
| Series | 1 |
| Capacity | 7 - 10 gpm28 - 40 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 175 psi12 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .02 in³0,33 cc |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-061-006 |
