SUN HYDRAULICS
CXIDLBV
$177.90 USD
Tags:
- SUN HYDRAULICS
- Material:CXIDLBV
- Model:CXID-LBV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXIDLBV (CXIDLBV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model is engineered to allow free flow from inlet port 2 to outlet port 1 while blocking flow in the opposite direction, making it an essential component for systems where manifold drillings may be incorrectly executed. The CXIDLBV features a T18A cavity and belongs to the Series 4, ensuring compatibility and ease of integration with various setups. With a capacity of up to 120 gpm (480 L/min) and a maximum operating pressure of 5000 psi (350 bar), this valve is equipped to handle demanding applications. It showcases an extremely low leakage rate, with maximum valve leakage specified at less than 1 drop per minute (0.07 cc/min), thereby ensuring minimal fluid loss and enhanced system efficiency. The valve's construction includes Sun's floating style design which minimizes the risk of internal parts binding due to excessive installation torque or cavity/cartridge machining variations. The CXIDLBV has a hex size of 1-5/8 inches (41.3 mm) and requires an installation torque between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm). Weighing in at approximately 2.10 lbs (0.95 kg), it is robust yet relatively lightweight for its capabilities. Additionally, it can accommodate Viton seals through the seal kit/cartridge part number 990018006, further enhancing its versatility and durability in various hydraulic environments. This check valve is ideal for applications needing precise flow control without sacrificing system integrity or performance.
The Sun Hydraulics CXIDLBV (CXIDLBV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model is engineered to allow free flow from inlet port 2 to outlet port 1 while blocking flow in the opposite direction, making it an essential component for systems where manifold drillings may be incorrectly executed. The CXIDLBV features a T18A cavity and belongs to the Series 4, ensuring compatibility and ease of integration with various setups. With a capacity of up to 120 gpm (480 L/min) and a maximum operating pressure of 5000 psi (350 bar), this valve is equipped to handle demanding applications. It showcases an extremely low leakage rate, with maximum valve leakage specified at less than 1 drop per minute (0.07 cc/min), thereby ensuring minimal fluid loss and enhanced system efficiency. The valve's construction includes Sun's floating style design which minimizes the risk of internal parts binding due to excessive installation torque or cavity/cartridge machining variations. The CXIDLBV has a hex size of 1-5/8 inches (41.3 mm) and requires an installation torque between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm). Weighing in at approximately 2.10 lbs (0.95 kg), it is robust yet relatively lightweight for its capabilities. Additionally, it can accommodate Viton seals through the seal kit/cartridge part number 990018006, further enhancing its versatility and durability in various hydraulic environments. This check valve is ideal for applications needing precise flow control without sacrificing system integrity or performance.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
