SUN HYDRAULICS
CSAWBXV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CSAWBXV (CSAWBXV) is a meticulously engineered shuttle valve designed for hydraulic systems requiring reliable pressure selection between two sources. This model incorporates a single ball shuttle mechanism that selects the higher of two pressures presented at its work ports, directing it to a common or signal port. The external sensing port located in the hex end of the cartridge allows for precise monitoring and control. The CSAWBXV is built with durability and performance in mind, featuring hardened steel balls and seats which enhance wear characteristics and improve tolerance to contamination. With a flow capacity of 1.25 gpm (4.7 L/min) and an ability to handle maximum operating pressures up to 5000 psi (350 bar), this valve is suitable for high-demand applications. It also boasts minimal leakage, with a maximum valve leakage rate of 5 drops per minute at 110 SUS (24 cSt). This model benefits from Sun's floating style construction which reduces the risk of internal parts binding due to installation torque or variations in cavity/cartridge machining. The CSAWBXV has specific installation requirements, with a valve hex size of 3/4 in. (19.1 mm) and an installation torque range of 20 - 25 lbf ft (27 - 33 Nm). Weighing just .20 lb (0.10 kg), it is compact yet robust enough to meet rigorous industrial demands without compromising performance. Additionally, it uses Viton seals for enhanced durability against high temperatures and chemical exposure, ensuring long-term reliability in diverse operating environments.
