Hydac-3049270-3049270

HYDAC
3049270


$118.65 USD
  • HYDAC
  • Material:3049270
  • Model:VALVE W/O COIL
  • Summary:WS16Z-01-C-N-0 WITHOUT COIL

Quantity in stock: 0

Note: Sales tax, and shipping will be calculated at checkout.

 The solenoid-actuated 2/2 directional poppet valve WS16Z is a pilot operated cartridge valve. In de-energized mode it is closed from port 2 to 1. In the opposite direction it acts as a check and permits flow from port 1 to 2. When energized it permits flow from port 2 to 1. Cavity UNF 1 5/16-12. Qmax = 150 l/min Pmax = 350 bar
