HENGST
1020860B

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hengst directly.***
The Hengst 110LEN0250-2X/PWR20A00-V2,2-M-R6 (1020860B) is a hydraulic-inline filter designed for the filtration of solids from fluids in hydraulic systems and lubricating oil systems. This inline filter is intended for installation in pipelines and features a robust construction with an aluminum housing material. It utilizes a multilayer glass fiber material (PWR20) as its filter media, which provides effective filtration with a grade of 20 microns. The filter is equipped with an NBR seal, designated by the seal code 'M', ensuring reliable sealing performance under various operating conditions. It has a nominal size of 0250 and is capable of handling a maximum working pressure of 110 bar, matching its nominal pressure rating. The design includes an optical indicator to provide visual feedback on the system's performance, with a switching point set at 2.2 bar. The Hengst inline filter also incorporates features such as suitability for HFC/HFA fluids and compliance with DIN24550 standards, making it versatile for different applications. Its port configuration follows ISO228-1 standards with G1 1/2 horizontal ports designated by port code 'R6'. Additionally, the filter's cyclone effect enhances particle removal efficiency. With a collapse pressure rating of 30 bar and bypass cracking pressure at 3.5 bar, this single design class inline filter ensures reliable operation even under demanding conditions. The standard support cage material further adds to its durability while the top mounting orientation allows for convenient installation within various pipeline setups.
