HENGST
1012345B

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hengst directly.***
The Hengst 100 FLE 0120 PWR6-A00-00V5,0-S0M00 (1012345B) is a hydraulic-inline filter designed for efficient filtration of solids from fluids in hydraulic systems and lubricating oil systems. This inline filter is intended for installation in pipelines and features a robust construction with nodular cast iron and carbon steel housing, ensuring durability under demanding conditions. The filter utilizes a multilayer glass fiber material, designated as PWR6, which provides a filtration grade of 6 to effectively capture contaminants. With a nominal size of 0120, the filter is equipped with an NBR seal and supports standard cage material configuration. It is suitable for use with HFC and HFA fluids but not compliant with DIN24550 standards. The Hengst inline filter can withstand a maximum working pressure of 100 bar and has a collapse pressure rating of 30 bar, making it reliable for high-pressure applications. Its port designation includes a 3\" - 3000psi SAE standard port positioned horizontally for easy integration into existing systems. The mounting is designed at the back, further facilitating straightforward installation. Additionally, the filter features an optical indicator to provide visual feedback on its operational status, with a switching point set at 5 bar. This feature enhances maintenance efficiency by allowing timely interventions before critical thresholds are reached. Overall, the Hengst hydraulic-inline filter offers robust performance capabilities tailored to meet the demands of modern hydraulic systems while ensuring fluid cleanliness and system longevity through effective solid particle filtration.
