HENGST
1012241B

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hengst directly.***
The Hengst 10TEN0250-PWR20A00-P2,2-V-R6 (1012241B) is a hydraulic tank-mounted return line filter designed for efficient filtration of solids from liquids in hydraulic or lubrication systems. This single design class filter is mounted at the tank top and features a multilayer glass fiber material configuration identified by the filter media code PWR and designation PWR20. It has a nominal size of 0250 and is equipped with an FKM seal, designated by seal code V, ensuring durability and reliable sealing performance. The filter housing is made of aluminum, providing strength while keeping the unit lightweight. Engineered to withstand a collapse pressure rating of 30 bar, this filter can operate effectively under a maximum working pressure of 10 bar. It includes an optical indicator for monitoring purposes, with a switching point set at 2.2 bar, allowing users to easily determine when maintenance or replacement is necessary. The bypass cracking pressure is rated at 3.5 bar, ensuring that the system continues to function optimally even if the filter becomes clogged. The Hengst model features G1 1/2 port designation with horizontal positioning compliant with ISO228-1 standards, facilitating straightforward integration into existing systems. Its suitability for HFC and HFA fluids adds versatility in various applications requiring specific fluid compatibility. Designed for easy installation on liquid containers within hydraulic systems, this product provides efficient filtration while maintaining system integrity and performance over time.
