BOSCH REXROTH
R911173040
- BOSCH REXROTH
- Material:R911173040
- Model:VPP60.3FEL-4G0NN-D5D-HN-NN-FW
Quantity in stock: 0
Model: FWA-VP3***-W7*-01VRS-A0-OEM A1
General data
|
Type |
VPP60.3FE | |
|
Color |
RAL 7035 light gray | |
|
Weight, 1/2 slot |
kg |
7.9 |
|
Weight, 4 slot |
kg |
8.7 |
|
Ambient temperature (operation) |
+5 °C ... +45 °C | |
|
Permissible relative humidity (operation) |
5 % ... 85 %, EN 61131-2 | |
|
Protection type front |
IP65 | |
|
Protection type rear |
IP20 | |
Processor
|
Type |
VPP60.3FE | |
|
CPU |
Celeron P4500 1.86 GHz, Core i5-520M 2.4 GHz, Core i7-620M 2.66 GHz - - |
|
|
Operating system |
Windows XP, Windows 7 | |
Hardware
|
Type |
VPP60.3FE | |
|
PCI/PCIe slots |
1/0; 2/0; 1/1; 4/0; 2/2 - |
|
|
Hard disk |
1 x 320 GB (standard) | |
|
Hard disk (RAID 1) |
2 x 320 GB (option) | |
|
Solid State Disk SSD |
192 GB (option) | |
|
DVD-ROM/DVD-RW |
DVD burner (option) | |
Memory
|
Type |
VPP60.3FE | |
|
Application/application |
GB |
2 4 - |
Display
|
Type |
VPP60.3FE | |
|
Type |
TFT - - |
|
|
Size |
48.3 cm/19 in | |
|
Colors/grayscales |
16 mill. colors | |
|
Resolution |
1280 x 1024 | |
Operation
|
Type |
VPP60.3FE | |
|
Type |
Touch operation - - |
|
|
Keyboard |
Additional component VAK | |
|
Status LED |
Voltage Hard disk Temperature UPS |
|
Interfaces
|
Type |
VPP60.3FE | |
|
Type |
2 x Ethernet TCP/IP (1 Gbits/s) 1 x USB 2.0 front 6 x USB 2.0 - |
|
|
External service monitor |
1 x VGA | |
Electrical data
|
Type |
VPP60.3FE | |
|
Supply voltage U |
V DC |
24 |
|
Umin ... Umax |
19 V DC ... 30 V DC | |
|
Power consumption |
W |
160 |
|
UPS |
External | |
Mechanical tests
|
Type |
VPP60.3FE | |
|
Vibration resistance |
g |
1 |
|
Shock resistance |
g |
15 |
Slide-out keyboards
VAK40
Slide-out keyboards
VAK40
Slide-out keyboard with integrated mouse Overall width 407 mm, suitable for 15” devices Suitable for devices in the VDP40, VPP40 and VEP50 series Protection type IP65Project planning guide
CAD Download
Foil keyboards
VAK11/41
Foil keyboards
VAK11/41
Foil keyboard with separate numeric block Overall width 350 mm or 407 mm, suitable for 12” and 15” devices Suitable for devices in the VDP16/40, VPP16/40 and VEP40/50 series Protection type IP65Project planning guide
CAD Download
Dimensions
|
Type |
VPP60.3FE | ||
|
4 slot |
A |
mm |
483 |
|
B |
mm |
400 | |
|
C1 |
mm |
22.5 | |
|
C2 |
mm |
129 | |
|
X |
mm |
483 | |
|
in |
19 | ||
External 24 V power supply unit
VAP01
External 24 V power supply unit
VAP01
External 24 V power supply unit for VEP, VPP, VPB and VDP devices Input voltage 100-120 or 200-240 V AC Output voltage 24 V DC Output power up to 288 W Output current up to 12 AApplication description
Uninterruptible power supply
VAU
Uninterruptible power supply
VAU
Uninterruptible power supply for VPP and VPB devices Output voltage 24 V DC Output power 240 W Bridging time 3 minutes USB interfaceApplication description
Y-repeater
VAC01
Y-repeater
VAC01
Increases the maximum distance between the industrial PC and display/terminal to 100 m Connection of two displays/terminals to one industrial PC possible (with cascading design up to four displays/terminals per industrial PC) Assignment of operating rights via the 24 V input on the Y-repeater Same display on all displays/terminalsApplication description
Norms and Standards
|
Type |
VPP60.3FE | |
|
Certification |
CE UL CSA - - - - |
|
