BOSCH REXROTH
R911171024
$1,786.77 USD
- BOSCH REXROTH
- Material:R911171024
- Model:VAU01.1U-024-024-240-NN
Quantity in stock: 0
Unpacked Weight: 4.3 kg
| Output current | 10 |
| Width | 123 |
| Productgroup ID | 4,6 |
| Input voltage | DC 24 V |
| Height | 145 |
| Device assignment | VSP/VPP/VSB/VPB |
| International protection code | IP20 |
| Communication | USB |
| Depth | 128 |
| Output power | 240 |
| Output voltage | DC 24 V |
| Weight | 4.3 |
Electrical data
|
Type |
VAU01.1U-024-024-240-NN | |
|
Current consumption at nominal voltage 1) |
A |
≤ 12 |
|
Interference and surge immunity |
UMax = 35 V (for t = 100 ms) | |
| 1) | 2 A for charging the battery |
Inputs
|
Type |
VAU01.1U-024-024-240-NN | |
|
Nominal input voltage UINenn |
V DC |
24 |
|
Permissible nominal input voltage range |
24 V DC (-15 ... +20 %) | |
|
Input fuse |
None | |
|
Switch-on threshold |
22 V ±5 % | |
|
Switch-off threshold |
19 V ±5 % | |
|
Power consumption 1) |
W |
≤ 288 |
|
Reverse polarity protection inputs |
Yes | |
| 1) | Of which 48 W for charging the battery |
Outputs
|
Type |
VAU01.1U-024-024-240-NN | |
|
Nominal output voltage UOut |
V DC |
24 |
|
Output voltage range |
24 V DC (-15 … +20 %) | |
|
Current output at UNenn |
A |
≤ 10 |
|
Switchover time |
ms |
< 1 |
|
Bridging time |
min |
≤ 3 |
|
Output power |
W |
≤ 240 |
|
Short-circuit protection |
No | |
|
Capacitive load |
µF |
≤ 5600 |
Dimensions
|
Type |
VAU01.1U-024-024-240-NN | |
|
A |
mm |
120 |
|
B1 |
mm |
147 |
|
B2 |
mm |
158.5 |
|
C1 |
mm |
29.7 |
|
C2 |
mm |
126.5 |
