BOSCH REXROTH
R911170968
$6,574.00 USD
- BOSCH REXROTH
- Material:R911170968
- Model:VAM40.2-PB-NA-TA-TA-VB-HA-1608-NN
Quantity in stock: 0
Unpacked Weight: 2.5 kg
| Mechanical strength | 1g vibration / 15g shock |
| Width | 407 |
| Productgroup ID | 4,6 |
| Input voltage | DC 24 V |
| Height | 169 |
| Device assignment | VSP/VPP40 |
| International protection code | IP54 |
| Communication | PROFIBUS DP |
| Depth | 53 |
| Weight | 2.5 |
General data
|
Type |
VAM 40.2 | VAM 40.3 | |
|
Colors |
RAL 7035 light gray | ||
|
Weight |
kg |
1.4 | 1.4 |
|
Protection type front |
IP54 | ||
Operation
|
Type |
VAM 40.2 | VAM 40.3 | |
|
Type |
Machine control panel for standard machine tools - - |
||
|
Function keys |
30 short-stroke keys, 1 authorization key-operated switch, 1 emergency off key, 1 feed override rotary switch, 1 spindle override rotary switch, 1 on-off key | 30 short-stroke keys, 1 emergency off key, 1 feed override rotary switch, 1 spindle override rotary switch, 1 on-off key | |
Interfaces
|
Type |
VAM 40.2 | VAM 40.3 | |
|
Fieldbus system |
1 x PROFIBUS DP slave (standard) - - - |
1 x Sercos III (standard) - - - |
|
Electrical data
|
Type |
VAM 40.2 | VAM 40.3 | |
|
Logic supply UL |
V DC |
24 | 24 |
|
A |
≤ 0.5 | ≤ 0.5 | |
|
Supply UQ |
V DC |
24 | 24 |
| 19 V DC ... 30 V DC | |||
|
A |
≤ 1.7 | ≤ 1.7 | |
Mechanical tests
|
Type |
VAM 40.2 | VAM 40.3 | |
|
Vibration resistance |
g |
0.5 | 1 |
|
Shock resistance |
g |
15 | 15 |
Dimensions
|
Type |
VAM 40.2 | VAM 40.3 | |
|
A |
mm |
407 | 407 |
|
B |
mm |
169 | 169 |
|
C1 |
mm |
48.85 | 43.5 |
|
C2 |
mm |
49.15 | 53 |
Norms and Standards
|
Type |
VAM 40.2 | VAM 40.3 | |
|
Certification |
CE UL CSA |
||
